EVE 3.2V 105ah LF105 Prismatic LiFeP04 Battery Cell
Suit for System: 12V 24V 48V 64V 72V 96V 108V 115V 288V.
Applicantion: RV /Vans /Campers /EV /Boats /Yacht /Golf Carts/ Forklift /Solar Battery/Solar Energy Storage System
To use in 48V system, you need 16pcs
To use in 24V system, you need 8pcs
To use in 12V system,you need 4pcs
Customized logo (Min. order: 200 pieces)
Customized packaging (Min. order: 200 pieces)
Graphic customization (Min. order: 200 pieces)
Delivery: 15 Days
OEM / ODM: Yes
Delivery Terms: FOB, EXW, CIF
Payment: T/T, L/C, PayPal
Air / Sea Freight: 10FT, 20FT, 40FT, 40FT HC, and 45FT
Brand New Grade A EVE 3.2V 105 Ah prismatic lithium iron phosphate lifepo4 batteny celLs
- High-Performance Battery Cell: LiFePO4 Cells 3.2V 304Ah EVE Battery Grade A Deep Cycle Lithium Iron Phosphate Rechargeable Battery with QR Code,Screws and Connectors,Power Supply for Solar Systems,Golf Cart,Motor,Off Grid.
- Wide Operating Temperature Range: Supports more than 4,000 cycles (80% DOD), signifcantly reducing long-term use costs. Single cell capacity of 105Ah optimizes energy storage
- Excellent consistency: The cell internal resistance, voltage and capacity are highly consistent, which is convenient for large-scale series and parallel use, and is suitable for the modular design of energy storage and power systems.Suitable for large-scale modular applications.
- Customizable Options: As an ODM/OEM product, this battery cell can be customized to meet specific user requirements, such as the user’s application (boats, electric forklifts, electric vehicle communications energy storage intelligent network), making it a versatile and adaptable solution.
Other attributes
| Model Number | LF105 |
|---|---|
| Brand Name | EVE |
| Weight | 5450±164g |
| Place of Origin | GUA |
| Product name | 3.2v 105ah Lifepo4 Battery Cell |
| Certificate | Certificate |
| Operating Temperature | Discharge: -20-55°C, Charge: 0-55°C |
| Cycle life | ≥4000 cycles (25°C) |
| Type | Life4po Battery |
| Voltage | 3.2v~ 3.65v |
| Pulse charge / discharge (30s) | 2C/2C |
| Size | 207.5±0.5 × 173.9±0.5 × 71.7±0.8 MM |
| OEM/ODM | Acceptable |
Packaging and delivery
| Selling units | Single item |
|---|---|
| Single package size | 19.55× 13.3 × 3.68cm |
| Single gross weight | 5.000 kg |
Lead time
| Quantity (pieces) | 1 – 1000 | 1001 – 100000 | 100001 – 100000000 | > 100000000 |
| Lead time (days) | 16 | 18 | 30 | To be negotiated |
Product descriptions
EVE LiFePO4 cell 3.2V 32Ah to 314Ah, various capacities are available. LiFePO4 Battery cells come in sets of 4 pieces.
You can make your battery packs for Trolling Motor, Boat, RV, Solar, Marine, Home Energy Storage, UPS power supply, replacing lead-acid batteries, etc.
The Lifepo4 cell with the latest production date
| 3.2V Cell parameters | |||||||
| Battery Cell Name | Capacity (Ah) |
Battery Cell cycle (25℃) |
AC Impedance Resistance (1kHz) |
Weight (g) |
Height (mm) |
Width (mm) |
Thickness (mm) |
| 3.2V50AH | 50AH | 1500 (0.5C/0.5C) |
≤2.0mΩ | 1050±100 | 129.8±0.5 | 148.3±0.5 | 26.7±1.0 |
| 3.2V50AH | 50AH | 7000 (1C/1C) |
≤0.7mΩ | 1395±50 | 185.3±0.5 | 135.3±0.5 | 29.3±0.7 |
| 3.2V105AH | 105AH | 4000 (0.5C/0.5C) |
≤0.32mΩ | 1980±60 | 200.5±0.5 | 130.3±0.5 | 36.35±0.5 |
| 3.2V173AH | 173AH | 4000 (0.5C/0.5C) |
≤0.25mΩ | 3190±96 | 207.5±0.5 | 173.9±0.5 | 41.06±0.5 |
| 3.2V230AH | 230AH | 4000 (0.5C/0.5C) |
≤0.2mΩ | 4140±124 | 207.2±0.5 | 173.9±0.5 | 53.85±0.5 |
| 3.2V280AH | 280AH | 8000 (0.5C/0.5C) |
≤0.25mΩ | 5490±300 | 207.2±0.5 | 173.7±0.5 | 71.7±0.8 |
| 3.2V304AH | 304AH | 4000 (0.5C/0.5C) |
≤0.16mΩ | 5450±164 | 207.2±0.5 | 173.7±0.5 | 71.7±0.8 |
We are an authorized distributor of EVE and supply Grade A, brand new 105Ah LiFePO4 battery cells with guaranteed capacity. Each set includes free copper bus bars, screws, and washers.
Our batteries come with UN38.3, MSDS, and UL certificates upon request. You can trust that you’re getting high-quality, safe, and reliable EVE cells that meet international standards.
Whether for solar systems, off-grid living, or business projects, our expert team is here to help you choose the perfect lithium battery solution.
👉 Contact us today for the latest prices, technical support, or bulk order inquiries — and power your projects with confidence!
